Single Mode Fiber Optic Patch Cord with APC ≥60dB UPC ≥50dB and PC ≥45dB Return Loss for FTTH CATV Telecom

Merknaam:	WNRLN
Modelnummer:	OS2-POL-SM-002
Moq:	10 stuks
Prijs:	USD 0.80-7.50 / Piece
Verpakking:	Individuele PE-zak met stofkappen, doos met WNRLN-merk, golfkarton van exportkwaliteit
Betalingsvoorwaarden:	T/T,L/C,PayPal,Western Union

Gedetailleerde informatie

Productbeschrijving

Gedetailleerde informatie

Plaats van herkomst:

Guangdong, China

Certificering:

ISO 9001:2015, RoHS, CE, TIA/EIA-568-C.3

Vezeltype:

OS2 Enkele modus (G652D / G657A1 / G657A2)

Connectortypen:

SC, LC, FC, ST, E2000

Poolse type:

UPC/APC/PC

Insertieverlies (UPC):

≤0,20dB Typisch, ≤0,30dB Max

Insertieverlies (APC):

≤0,20dB Typisch, ≤0,30dB Max

Retourverlies (UPC):

≥50db

Retourverlies (APC):

≥60db

Retourverlies (pc):

≥45db

Kabeldiameter:

0.9mm / 2.0mm / 3.0mm

Jasmateriaal:

PVC / LSZH / OFNP / OFNR

Ferrule materiaal:

Zirkonia keramiek

Bedrijfsgolflengte:

1310nm / 1550nm

Bedrijfstemperatuur:

-40 ° C tot +75 ° C

Levering vermogen:

100.000 stuks per maand

Markeren:

UPC APC PC Polish Patch Cord

Single Mode OS2 SC LC Connector

High Return Loss FTTH CATV Jumper

Productbeschrijving

UPC/APC/PC Polish Single Mode Fiber Optic Patch Cord

Polish Types & Specifications

🟢

APC Polish (8° Angled)

≥60dB return loss with 8° angled end-face. Green connector body. The industry standard for CATV, RF over fiber, and FTTx PON networks where back reflection must be minimal.

🔵

UPC Polish (Ultra Physical Contact)

≥50dB return loss with domed end-face. Blue connector body. Ideal for telecom backbone, data center, and enterprise networks requiring stable low-loss connections.

⚫

PC Polish (Physical Contact)

≥45dB return loss with slightly domed end-face. Cost-effective solution for legacy installations and applications where ultra-high return loss is not critical.

Polish Type Comparison

Parameter	PC Polish	UPC Polish	APC Polish
End-Face Geometry	Slight Dome	Extended Dome	8° Angled
Return Loss	≥45dB	≥50dB	≥60dB
Insertion Loss (Typical)	≤0.30dB	≤0.20dB	≤0.20dB
Connector Body Color	Black / Beige	Blue	Green
Best Application	Legacy Systems	Telecom / Data Center	CATV / FTTx / RF

Technical Specifications

Fiber Type: OS2 Single Mode (G652D / G657A1 / G657A2)

Connector Types: SC, LC, FC, ST, E2000

Polish Options: UPC / APC / PC

Core Count: Simplex / Duplex

Cable Diameter: 0.9mm / 2.0mm / 3.0mm

Jacket Material: PVC / LSZH / OFNP / OFNR

Operating Wavelength: 1310nm / 1550nm

Operating Temperature: -40°C to +75°C

Ferrule Material: Premium Zirconia Ceramic

Test Standard: 100% OTDR Tested, IEC 61300-3-6 Compliant

Applications by Polish Type

APC — CATV & RF Over Fiber

FTTH PON, HFC networks, analog video transport, GPON/EPON OLT to ONU links

UPC — Telecom & Data Center

DWDM systems, SDH/SONET backbone, SAN fabric, enterprise structured cabling

PC — Legacy Installations

Existing multimode networks, test equipment connections, non-critical monitoring systems

Quality Assurance & Factory Direct Supply

Every patch cord undergoes 100% OTDR testing and end-face 3D interferometry inspection. Custom polish type, connector combination, and cable length available. Contact us for OEM/ODM inquiries and bulk wholesale pricing.

100% OTDR Tested 3D Interferometry ISO 9001 Factory Custom OEM/ODM
